Driven Roller

Descriptions:

The load capacity is decided by "o" belt drive power and driving device for these series(single groove shaft line driving is higher than double one,the position of groove is customized by customer),the reference date is usually within 300N,suit for light duty conveying. Advantages: light weight,nice operating performance.polymerbearing components (can made for anti-static agent),nice appearance. Polymer end cap has the function of dust proof and water slash proof.The weight of subject can't exceed 80kgs. Disadvantages:cause the material is polymer,not applicable in high temperature environment.

Products Features:

1.Polymer sprocket and accumulating sleeve, Abrasion resistant and self-lubricating

2.The load capacity can be around 80-kg,suitable for light duty conveying, same size as B212/B213, these two types can be mutual combined, especial in the functional operation.

3.Simple structure, groove position customized

4.Quiet operation, Standard anti-static design

5.Application for light & middle duty
